リアサスペンション片側のみ/RACING SPEC(GT-Rリアナックル対応)
RACING SPEC(GT-Rリアナックル対応)のリアサスペンションを、Assyで交換する為の補修部品となります。
RACING SPECサスペンションのGT-Rリアナックル対応モデルです。大会参戦者上位の方は、ナックルの強度もあり 軽量なGT-R用へ変更する方が大半です。ただシルビアからGT-Rへはそのまま装着できませんの で、GT-Rナックル対応モデルのRACING SPECバージョンを制作しました。
■適合型式
型式 | CS14/S14/S15 |
---|
仕様/リア
倒立/正立 | 正立 |
---|---|
メイン自由長 | 220mm |
メインスプリングレート | 9Kgf/mm |
メインスプリングタイプ | 直巻 |
メインスプリング内径 | 62Ф |
アッパーマウント | ピロ |
全長調整 方法 | フルタップ式 |
減衰力調整方法 | ダイヤル式 |
減衰調整 | 30段階 |
対応ナックル
対応ナックル(アルミ) | BCNR33/BNR34 |
---|
※伸び側・縮み側の2wayで独立調整が可能
This is a repair part for replacing the RACING SPEC (GT-R rear knuckle compatible) rear suspension with an assembly.
This is a RACING SPEC suspension model compatible with the GT-R rear knuckle. Most of the top competitors in competitions change to the GT-R version, which has stronger knuckles and is lighter. However, since it cannot be directly installed on a Silvia to a GT-R, we have created a RACING SPEC version of the model compatible with the GT-R knuckle.
■Compatible model
Model code | CS14/S14/S15 |
---|
Specifications/Rear
Handstand/erect | erect |
---|---|
Main free length | 220mm |
Main spring rate | 9Kgf/mm |
Main spring type | Straight winding |
Main spring inner diameter | 62Ф |
Upper mount | Pillow |
Overall length adjustment method | Full tap type |
Damping force adjustment method | Dial type |
Damping adjustment | 30 stages |
Compatible knuckles
Compatible knuckles (aluminum) | BCNR33/BNR34 |
---|
*Independent adjustment possible in two ways for the extension and compression sides
